DCS-25PV5 Vertiacl Impeller Valve Bagging Machine Weighing Filling Sealing Machine
1 Set
MOQ
Negotiable
Price
DCS-25PV5 Vertiacl Impeller Valve Bagging Machine Weighing Filling Sealing Machine
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Suzhou
Brand Name: Sanhe
Certification: ISO9001:2015, CE
Model Number: DCS-25PV5 (vertiacl impeller)
High Light:

valve bag filling machine

,

valve bag packing machine

Payment & Shipping Terms
Packaging Details: Wood Pallet
Delivery Time: 90 days
Payment Terms: L/C, T/T
Supply Ability: 90 Sets Per Month
Specifications
Item: Weighing Filling Sealing Machine
Function: Valve Bag Weighing Filling Packing Sealing
Production Capacity: 90 Sets Per Month
Controls: PLC
Powder: Electric
Origin: Suzhou
Product Description
DCS-25PV5 Vertiacl Impeller Valve Bagging Machine Weighing Filling Sealing Machine

DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 0

DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 1



A. What is 25 kg electronic packing scale:

Electronic packing scale consists of weighing unit, sewing machine, conveying device, pneumatic system, dust removal system, quantitative packing control, etc. the whole weighing process is controlled by PLC and completed automatically.





B. Working principle of 25 kg electronic packaging scale:

When the electronic packaging scale enters the automatic operation state, the weighing control system opens the feeding door to start feeding, which is a fast and slow feeding mode; when the material weight reaches the fast feeding setting value, stop the fast feeding and keep the slow feeding; when the material weight reaches the final setting value, close the feeding door to complete the dynamic weighing process;



At this time, the system checks whether the bag clamping device In the predetermined state, when the packaging bag has been clamped, the system sends a control signal to open the unloading door of the weighing bucket, and the material enters the packaging bag.



The bag clamping device will be released, and the packaging bag will fall automatically; after the packaging bag falls, the sewing bag will be carried out and transported to the next station. It operates automatically in such a cycle.





C. Generally, a packing & palletizing line includes: Electric Cabinet, sewing machine,Sewing conveyor, Bag push machine, Reshapen conveyor,Metal detector,Weight checker,Bag Rejecter,Ink-jet printer conveyer,Ink-jet printer ,Pallet magazine,Palletizing conveyor ,Robot, Wrapping Machine ,Finished palletizing conveyor.



D. According to the different styles of packaging bags, it can be divided into open mouth bag packing machine and valve type bag packing machine


Main specialty :
 Valve bag packing for Powder and ultrafine powder.
 Can be twin-type packer
 Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.

The parameter and function table :

DCS-25PV1(5) (vertiacl impeller)
Scope of application
Suitable materials
Powder and ultrafine powder
Suitable packing container
Vertical impeller
Technical parameters
Weighing range(Kg)
10-50
Packing speed(bag/H)
30-250
Packing Accuracy
Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)


Our Services :
1. one year guarantee for whole machine except for wear parts;
2. 24 hours technical support by email;
3. calling service;
4. user manual available;
5. reminding for the service life of the wearing parts;
6. installation guide for clients from both China and abroad;
7. maintance and replacement service;
8. whole process trainling and guidance from our technicians.High quality of after-sales service symbolizes our brand and ability. We pursue not only good quality products, but also best after sales service. Your satisfaction is our final purpose.

FAQ of Valve Bagging Machine
1. Are you a trading company or a factory?
---We are factory sell directly, and welcome to visit our factory in Changshu city,Suzhou,Jiangsu Province China.
2. Can you guarantee the quality of your valve bag packing machine?
---We have passed CE&ISO9001, and our packing machines have been sent to Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, America, etc.
3. How many years have you been manufacturing this machine?
---Since the foudation of our company, we have been manufacturing the machine, which updated many times, now the machine runs stable and of high quality.




Our core products is :
Big bag packing machine. 5kg-50kg .
Ton bag pack machine.
Ton bag discharger.
10L-1000L liquid filling machine.
Palletizing Line.

It sales well in China and overseas market.
Sanhe--A wellknown packing and palletizing manufacture from China



DCS-25PV5 Vertiacl Impeller Valve Bagging Machine Weighing Filling Sealing Machine 2


Valve Bag Packer



The parameter and function table of the valve bag packer:



DCS-25PV1(1)

(exhausting type)

DCS-25PV1(2)

(screw type)

DCS-25PV1(3)

(airflow type)

DCS-25PV1(5)

(horizontal impeller)

DCS-25PV1(6)

(vertiacl impeller)



Scope of application



Suitable materials



Powder and ultrafine powder of good Air affinity



Powder and thin granule



Powder and thin granule



Powder and ultrafine powder



Powder and ultrafine powder



Suitable packing container

Upper and lower spiral air supply single screw air flow Horizontal impeller Vertical impeller



Technical parameters



Weighing range(Kg)

10-50 10-50 10-50 10-50 10-50



Packing speed(bag/H)

30-180 30-120 30-200 30-250 30-250



Packing Accuracy



Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)



Control function



Automatic tare



Automatic quick and slow feeding



Automatic free fall compensation



Automatic minus deviation

× ×



Automatic over weight alarms



Automatic self diagnosis failure



Manual/Automatic mode conversation



Communication port



Regulatory function



Manual adjusting the height of bag



Suit for open and valve bag function



Important auxiliary function



Blow bag function in advance



Arch break function of hopper



Vibration at the bottom of the bag



Powder protection



Inflatable seal

× × ×



Negative pressure dusting(not contain duster)



Automatic blow valve mouth

×



Safety protection



Electrostatic grounding



ionic wind remove static



Stop packing when lose power



Emergency stop



Ex-proof



Mark: “○”is standard function;“▲”is choose function ;“×”is not has function





main features:

*valve bag packing for Powder and ultrafine powder.

*Can be twin-type packer

*Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.
