March 26, 2022
Scope of application: chemical,petrochemical, fine chemical, medicine, fertilizer, plastics, rubber, dyestuff, food, feed, non-ferrous metals, metallic minerals, nonmetallic minerals, building material industries etc.
Weighing method: by load cell
Automatically start, Automatically tare, Automatically free fall compensation.
Process Description :
1.Robot give empty bag.
2.Bag peeling.
3.Fast feeding.
4.Slow feeding.
5.Finish fillinging.
6.Heat sealing bag mouth.
Packing parameter for automatic electronic quantitive packing Machine:
| Material ( to be packed ) | Detergent powder |
| Particle size (mm): | 125-180μm |
| Bulk density kg/m³ : | 0.6-0.8 |
| Flow ability: | Good |
| static electricity : | no |
| Packing speed (bag/hour) | 50-100 bags/hour |
| Packaging weight | 25kg/bag |
| Weighing accuracy | ±0.2% |
| Type of bag | Open mouth bag |
| Body Fabric | PE |
| Empty bag Dimensions(L×W×H)(mm) | To be confirmed |
Materials of automatic electronic quantitive packing Machine construction:
| Wetted parts contacted with product | SS304 |
| wetted parts not contacted with product for packing machine | CS painted |
| wetted parts not contacted with product for others | CS painted |
| Flange | SS304 |
| gasket | Rubber |
| Flexible connection | Plastic or Rubber |
| Frame of conveyor | CS painted |
| Gear and chain | CS |
| Bolts & nuts for packing machine | SS304 |
| Bolts & nuts for others | CS galvanized |
JMD-500 automatic packaging line are composed of:
| Nub | Equipment | Quantity |
|
|
JMD-500 automatic electronic quantitive packing Machine | 1 |
|
|
Automatic empty bag supply machine | 1 |
|
|
Automatic heat sealing machine | 1 |
|
|
conveyor for heat sealing machine | 1 |
|
|
Push bag & reshaping conveyor | 1 |
|
|
Metal detector | 1 |
|
|
Weight checker | 1 |
|
|
eliminate Bag machine | 1 |
|
|
Ink-jet printer | 1 |
|
|
Ink-jet printer conveyor | 1 |
|
|
Buffer conveyor | 1 |
|
|
Bag feeding conveyor | 1 |
|
|
Robot palletizer | 1 |
|
|
Pallet magazine | 1 |
|
|
Palletizing conveyor | 1 |
|
|
Conveyor for forklift | 1 |
|
|
Power cabinet | 1 |
|
|
Control cabinet for conveyors | 1 |
and be already awarded ISO9001-2000 “Certificate of The System of Quality Certification” and “License for manufacturing measuring instruments of the People’s republic of China”(CMC). it has three Jiangsu Province Hi-tech Products . The enterprise has 104 employees , including 28 technicians.
**can you give a brief introduction of your factory ?
--we built in 1998, with 104 stuff now, China high-tech manufacture,
**whats your main products ?
1. 25 kg automatic ( open mouth bag ) weighing packing & palletizing line,
2. 25 kg automatic ( valve type bag ) packing & palletizing line,
3. ton bag packing machine.
4. liquid filling machine (10L-50L;/ 50L-250L; / 1500L)
5. Ton Bag Feeding Station Ton bag unpacking station.
6. stretch hood machine .
Frequently asked questions and answers :
**how many technic man do you have ?
--20 people .
**where is your factory locate?
--120 Km far north-west to shanghai city.
**what is the Annual output value of 2021 ?
--11,004,000 USD in 2021.
**what is your delivery time ?
-- normally 3 months for semi-automatic weighing bagging machine ; 4 months for the automatic bagging line;
**what certification do you have ?
--CE , ISO 9001 : 2015.
**what is the packing of products ?
--wooden pallet / wooden case.
**which port of yours ?
--Shanghai port.
**whats your market ? donestic or export ? what percentage for export ?
--china market 90% , 10% export .
**what fair do you attend ?
--PROPAK, Food additives fair, chemical fair, Pharmaceutical fair...
**what countries do you export to now ?
--Pakistan,India,Thailand ,Malaysia ,USA, Philippine , Indonesia, South Korea, Algeria ...
**how many people in QC team ? how do you make QC control ? internal or thrid party ?
--2 QC, internal QC control.
**are you open for OEM /ODM ?
--yes , available.
