A. What is 1000 kg electronic packing scale:
Electronic packing scale consists of weighing unit, sewing machine, conveying device, pneumatic system, dust removal system, quantitative packing control, etc. the whole weighing process is controlled by PLC and completed automatically.
B. Working principle of electronic packaging scale:
When the electronic packaging scale enters the automatic operation state, the weighing control system opens the feeding door to start feeding, which is a fast and slow feeding mode; when the material weight reaches the fast feeding setting value, stop the fast feeding and keep the slow feeding; when the material weight reaches the final setting value, close the feeding door to complete the dynamic weighing process;
At this time, the system checks whether the bag clamping device In the predetermined state, when the packaging bag has been clamped, the system sends a control signal to open the unloading door of the weighing bucket, and the material enters the packaging bag.
The bag clamping device will be released, and the packaging bag will fall automatically; after the packaging bag falls, the sewing bag will be carried out and transported to the next station. It operates automatically in such a cycle.
Suitable Packing Container : Open Mouth bag
|power voltage||380VAC 50Hz|
|Positive air pressure||0.5-0.8MPa|
|Negative air pressure||-0.075~-0.093MPa|
Q: what’s the package ?
A: Most of goods are packed in wooden box / wooden pallet
Q: Do you offer Installation & debugging?
A: Our engineers are available to service machinery overseas to help customers to solve machine problems.
Q: What’s policy for guarantee and broken parts ?
A: As for machine products, our company provides 12 months for all mechanical parts with the exception of electrical and electronic parts and those subjects to normal wear and tear. Meanwhile, the guarantee starts from the shipment (B/L date). The guarantee is intended limited to the replacement of the broken part after checking the construction fault. The inspection of the causes of the trouble or the breakdown of the parts is exclusively up to the manufacturing company. All in all, our company can offer you assured products.
High degree of automation,
automatic taring ,
easy to operate ;
95% of China Silica (white carbon black) factory use our packing scale machine.
|Packing Accuracy||Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)|
|Automatic quick and slow feeding||○||○||○||○|
|Automatic free fall compensation||○||○||○||○|
|Automatic minus deviation||▲||▲||▲||▲|
|Automatic over weight alarms||○||○||○||○|
|Automatic self diagnosis failure||○||○||○||○|
|Manual/Automatic mode conversation||○||○||○||○|
|Manual adjusting the height of bag||▲||▲||○||○|
|Automatic adjusting the height of bag||▲||▲||▲||▲|
|Manual adjusting the width of bag||▲||▲||▲||▲|
|Automatic blow bag in advance function||▲||▲||▲||▲|
