Auto 1000L Container IBC Filling Equipment Weighing With Roller Conveyor
1 Set
by negotiation
Auto 1000L Container IBC Filling Equipment Weighing With Roller Conveyor
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Sanhe
Certification: CE, ISO
Model Number: DCS-1000L
High Light:

Auto IBC Filling Equipment


1000L IBC Filling Equipment


Weighing IBC Filling Machine

Payment & Shipping Terms
Packaging Details: 100 Sets One Month
Delivery Time: 30-90 work days
Payment Terms: T/T
Product Name: Auto IBC Filling Machine
Driven Type: Electric
Voltage: AC 380/220 V
Filling Accuracy: 1g,10g,20g, ≤0.1%
Bottle Type: Drum, Barrel, Can
Packing Material: Wood Packing
Filling Speed: 130-200kg / Min
Filling Volume: 1000L
Product Description

Auto 1000L Container IBC Filling Machine Weighing Filler With Roller Conveyor


Product Description:
Accuracy and a high degree of safety during product filling are basic requirements that must be met by IBC Filling Machine that meets the highest quality standards. Whether your product is a non-critical, foaming, explosive or flammable commodity, fill as a filling equipment specialist
Appropriate filling techniques will be provided. All automatic pallet IBC Filling Machine have a standardized working principle. Trays arrive at the automatic filling machine empty, clean or possibly closed and filled with calibrated precision, clean and closed. The core components of IBC Filling Machine are the filling valve and the weighing scale.
The filling operation is carried out using the tried-and-true coarse/fine filling process. In order to comply with the calibration error limits, IBC Filling Machine is necessary to limit the volume flow at the end of the filling process.
★ Touch screen control, simple operation
★ The whole machine can be moved and flexible
★ The filling head can swing for easy filling


Product Paramenters
Filling Quantity
Barrel Specification
≤ diameter 1200* height 1200mm
Filling Index Value
1g, 10g , 20g
Filling Speed
130-200kg / Min
AC380/220 50HZ
Air Supply
0.6 MPa
Overall Dimension (mm)
● Instant working status indication and clock display
● Digital set input weight, multiple formulations stored
● Tare weight detection start a full range of bucket filling
● Gross/net weight (automatic peeling per barrel) filling method
● Automatic zero tracking, bucket quantity and weight accumulation
● Start automatically reset, power protection device
● Emergency stop protection device
● The factory settings can be restored by wrong operation
● With fault detection function, easy maintenance
● Flexible movement, explosion-proof configuration, simple operation
● Weight error automatic correction
Explosion-proof filling machine, the character designs, one operator, two barrels can be filled at a time,put the barrel location can be adjusted according to workers operation habit to filling, roller conveyor, filling height is adjustable.
liquid filling machine is suitable for filling all kinds of large barrels, such as round barrels and slant-mouth barrels, a variety of discharging mode set, meet customer multi-usage, many kinds of filling, mobility, and guarantee the fast speed filling accuracy, good stability, Reduce wastage, save cost and reduce operating pressure of workers.


High accuracy
Easy clean out and maintence
After liquid filling machine installs you get hands on training and documentation
The air flow feed system is capable of high production rates while maintaining good accuracies.
Operator friendly easy set
Universal and industrial components give the machinery extra long life
Manufactured to comply above and beyond international standards
PLC controller interface
The flexible and modular Packaging System


The follwing questions for us to help you find what you want ?

1, The material you want to pack and its size(μm, mm), bulk density(kg/m3)

2, Packing weight (kg/bag), capacity (t/day)

3, Detailed description of production line



Our Services of liquid filling machine :
1. one year guarantee for whole machine except for wear parts;
2. 24 hours technical support by email;
3. calling service;
4. user manual available;
5. reminding for the service life of the wearing parts;
6. installation guide for clients from both China and abroad;
7. maintance and replacement service;
8. whole process trainling and guidance from our technicians.High quality of after-sales service symbolizes our brand and ability. We pursue not only good quality products, but also best after sales service. Your satisfaction is our final purpose.
