DCS-25FWG Open Mouth Bagging Machine 25 kg Bag Weighing Filling Equipment

DCS-25FWG Open Mouth Bagging Machine 25 kg Bag Weighing Filling Equipment

DCS-25FWG Open Mouth Bagging Machine 25 kg Bag Weighing Filling Equipment
  • DCS-25FWG Open Mouth Bagging Machine 25 kg Bag Weighing Filling Equipment
Product Details:
Place of Origin: Suzhou
Brand Name: SANHE
Certification: ISO9001:2015, CE
Model Number: DCS-25FWG(PO1G-S)
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wood Pallet
Delivery Time: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 90 Set Per Month
Contact Now
Detailed Product Description
Product Pame: Open Mouth Bagging Machine Weighing Range: 5-50 Kg Per Bag
Packing Speed: 30-100 Bags Per Hour Accuracy: Generally (+/- )0.2%
Powder: Electric Origin: Suzhou
High Light:

open mouth bagging equipment

,

open mouth bag filling machines

DCS-25FWG Open Mouth Bagging Machine 25 kg Bag Weighing Filling Equipment



A. What is 25 kg electronic packing scale:

Electronic packing scale consists of weighing unit, sewing machine, conveying device, pneumatic system, dust removal system, quantitative packing control, etc. the whole weighing process is controlled by PLC and completed automatically.





B. Working principle of 25 kg electronic packaging scale:

When the electronic packaging scale enters the automatic operation state, the weighing control system opens the feeding door to start feeding, which is a fast and slow feeding mode; when the material weight reaches the fast feeding setting value, stop the fast feeding and keep the slow feeding; when the material weight reaches the final setting value, close the feeding door to complete the dynamic weighing process;



At this time, the system checks whether the bag clamping device In the predetermined state, when the packaging bag has been clamped, the system sends a control signal to open the unloading door of the weighing bucket, and the material enters the packaging bag.



The bag clamping device will be released, and the packaging bag will fall automatically; after the packaging bag falls, the sewing bag will be carried out and transported to the next station. It operates automatically in such a cycle.





C. Generally, a packing & palletizing line includes: Electric Cabinet, sewing machine,Sewing conveyor, Bag push machine, Reshapen conveyor,Metal detector,Weight checker,Bag Rejecter,Ink-jet printer conveyer,Ink-jet printer ,Pallet magazine,Palletizing conveyor ,Robot, Wrapping Machine ,Finished palletizing conveyor.



D. According to the different styles of packaging bags, it can be divided into open mouth bag packing machine and valve type bag packing machine



Main specialty :

Suit for material contain many air which use open mouth bag to packing.

Can exhausting the air in material, improve the bulk density of material in bag. It not wasting material.

Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.





The parameter and function table :

  DCS-25FWG(PO1G-S) Open Mouth Bagging Machine
Scope of application
Suitable materials Powder and thin granule of good Air affinity
Suitable packing container Open mouth bag
Feeding type Air flow type
Alternative feeding type Screw type
Technical parameters
Weighing range(Kg) 5-50
Packing speed(bag/H) 30-100
Packing Accuracy Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)





Features & advantages :
1. Good service
2. Fast delivery
3. PLC technology of electronically automatic measurement , accurate measurement, dust free.
4. High capacity
5. Reliable and durable, long lifecycle of spare parts.
6. Firm, durable, easy to use





Please Send us the Bagging Machine Details for Quatation  :

The material (to be packed) parameter :
A. Product name ?
B. Diameter of the material (um or mm) ?
C. Form of product ( Granule or powder ) ?
D. Bulk density(ton/m3) ?
E. Flow ability ?
F. Moisture absorption ?
G. Causticity ?
H. Toxicity ?
I. Degree of ex-proof protection for the packing machine parts ?


Packing Parameter  :
A. Packing speed (bag/hour) ?
B. Packaging weight per bag ( KG/bag ) ?
C. Weighing accuracy ?


Bag/Bucket Parameter:
A. Open mouth bag or valve type bag?
B. What material of the Bag/Bucket, PP bag, PE bag, Nylon Bag, Kraft paper, Paper-plastic composite (inner is plastic, outer is paper) ?
C. Bag size: width*height ( mm ) ?
D. Coiled bags or separate bags ?
