DCS-25FWG( PO3G-S) Open Mouth Packing Machine

DCS-25FWG( PO3G-S) Open Mouth Packing Machine

DCS-25FWG( PO3G-S) Open Mouth Packing Machine
  • DCS-25FWG( PO3G-S) Open Mouth Packing Machine
Product Details:
Place of Origin: Suzhou
Brand Name: Sanhe
Certification: ISO9001:2015, CE
Model Number: DCS-25FWG( PO3G-S)
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wood Pallet
Delivery Time: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 90 Sets Per Month
Contact Now
Detailed Product Description
Product Name: Open Mouth Bagging Equipment Weighing Range: 5-50 Kg Per Bag
Packing Speed: 30-100 Bags Per Hour Origin: Suzhou
Accuracy: Generally (+/- )0.2% Powder: Electric
High Light:

open mouth bagger

,

open mouth bag filling machines

DCS-25FWG( PO3G-S) Open Mouth Packing Machine

feeding type: air blow





A. What is 25 kg electronic packing scale:

Electronic packing scale consists of weighing unit, sewing machine, conveying device, pneumatic system, dust removal system, quantitative packing control, etc. the whole weighing process is controlled by PLC and completed automatically.





B. Working principle of 25 kg electronic packaging scale:

When the electronic packaging scale enters the automatic operation state, the weighing control system opens the feeding door to start feeding, which is a fast and slow feeding mode; when the material weight reaches the fast feeding setting value, stop the fast feeding and keep the slow feeding; when the material weight reaches the final setting value, close the feeding door to complete the dynamic weighing process;



At this time, the system checks whether the bag clamping device In the predetermined state, when the packaging bag has been clamped, the system sends a control signal to open the unloading door of the weighing bucket, and the material enters the packaging bag.



The bag clamping device will be released, and the packaging bag will fall automatically; after the packaging bag falls, the sewing bag will be carried out and transported to the next station. It operates automatically in such a cycle.





C. Generally, a packing & palletizing line includes: Electric Cabinet, sewing machine,Sewing conveyor, Bag push machine, Reshapen conveyor,Metal detector,Weight checker,Bag Rejecter,Ink-jet printer conveyer,Ink-jet printer ,Pallet magazine,Palletizing conveyor ,Robot, Wrapping Machine ,Finished palletizing conveyor.



D. According to the different styles of packaging bags, it can be divided into open mouth bag packing machine and valve type bag packing machine



The parameter and function table :

  DCS-25FWG(PO1G-S)Open pocket packer(positive pressure Exhausting)
Scope of application
Suitable materials Powder and thin granule of good Air affinity
Suitable packing container Open mouth bag
Feeding type air flow
Alternative feeding type ×
Technical parameters
Weighing range(Kg) 5-50
Packing speed(bag/H) 30-100
Packing Accuracy Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)


Product Characteristics of our 25 Kg Open Mouth Weighing Bagging Equipment
Designed with touch screen control and has much simplicity in its use. In addition, you can make adjustment on packaging sizes according to your needs.





FAQ :


Please Send us The Details We Required :
1. Name of Material to Be Filled in Bag?
2. Wight Capacity of Single Bag ?
3. How Much Bag Fill Per Hour?
4. Your Materials Characte?


Advantages of our 25 Kg Open Mouth Weighing Bagging Equipment

High accuracy
Easy clean out and maintence
After the machine installs you get hands on training and documentation
The air flow feed system is capable of high production rates while maintaining good accuracies.
Operator friendly easy set
Universal and industrial components give the machinery extra long life
PLC controller interface
The flexible and modular Packaging System





The follwing questions for us to help you find what you want ?

1, The material you want to pack and its size(μm, mm), bulk density(kg/m3)

2, Packing weight (kg/bag), capacity (t/day)

3, Detailed description of packing machine requirement.





Our core products are:

25 Kg Open Mouth Weighing Bagging Equipment

Automatic open mouth bag packing and palletizing line

Automatic valve bag packing and palletizing line

Automatic packing and palletizing line

Open mouth bag packing machine for granular

Open mouth bag packing machine for powder

Valve bag packing machine for granular

Valve bag packing machine for powder

Big bag packing machine

Big bag unloading station

Liquid filling machine

Various conveyors



It sales well in China and overseas market.
