Chemical 200bag/H 25kg Weighing Valve Bagging Machine
1 Set
MOQ
Negotiation
Price
Chemical 200bag/H 25kg Weighing Valve Bagging Machine
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Sanhe
Certification: CE,ISO9001:2015
Model Number: DCS-25PV3
High Light:

Weighing Valve Bagging Machine

,

200bag/H Valve Bagging Machine

,

25kg Valve Bag Packer

Payment & Shipping Terms
Packaging Details: Wood Pallet
Delivery Time: 90 days
Payment Terms: T/T, L/C
Supply Ability: 90 Sets Per Month
Specifications
Product Name: Weighing And Bagging Machine For Chemical Design Institute
For Bags Type: Valve Type Bag
Brand: SANHE
Certification: ISO9001:2015;CE
Drive: Electric
Apply For: Valve Bag Packing
Product Description

DCS-25PV3 Valve Bag Packer Weighing and bagging machine for Packing Association



A. What is 25 kg electronic packing scale:

Electronic packing scale consists of weighing unit, sewing machine, conveying device, pneumatic system, dust removal system, quantitative packing control, etc. the whole weighing process is controlled by PLC and completed automatically.

DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 0

DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 1



B. Working principle of 25 kg electronic packaging scale:

When the electronic packaging scale enters the automatic operation state, the weighing control system opens the feeding door to start feeding, which is a fast and slow feeding mode; when the material weight reaches the fast feeding setting value, stop the fast feeding and keep the slow feeding; when the material weight reaches the final setting value, close the feeding door to complete the dynamic weighing process;



At this time, the system checks whether the bag clamping device In the predetermined state, when the packaging bag has been clamped, the system sends a control signal to open the unloading door of the weighing bucket, and the material enters the packaging bag.



The bag clamping device will be released, and the packaging bag will fall automatically; after the packaging bag falls, the sewing bag will be carried out and transported to the next station. It operates automatically in such a cycle.





C. Generally, a packing & palletizing line includes: Electric Cabinet, sewing machine,Sewing conveyor, Bag push machine, Reshapen conveyor,Metal detector,Weight checker,Bag Rejecter,Ink-jet printer conveyer,Ink-jet printer ,Pallet magazine,Palletizing conveyor ,Robot, Wrapping Machine ,Finished palletizing conveyor.



D. According to the different styles of packaging bags, it can be divided into open mouth bag packing machine and valve type bag packing machine





Main specialty of our Valve Bag Packer :

 Valve bag packing for Powder and ultrafine powder.

  Can be twin-type packer
  Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.



The parameter and function table of the valve bag packer :


DCS-25PV1(3)(airflow type)
Scope of application
Suitable materials
Powder and thin granule
Suitable packing container
Airflow
Technical parameters
Weighing range(Kg)
25
Packing speed(bag/H)
30-200
Packing Accuracy
Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)





Product Characteristics:
Easy to operate and use
Bag-clamp equipment is advanced, material can be fully filled
Fill material system has material-stop equipment, accuracy high
Control, work parts all use imported parts, stable and reliable with sewing machine
Heat-sealing machine optional




Our Service :
1. We can provide "one-stop purchasing" or "package program" system solutions and owns professional manufacturing equipment as well as a full range of technical support and after-sale service.
2. OEM, Customized can be all accepted.
3. Contact us any time when you feel free.




FAQ :
Please Send us The Details We Required :
1. Name of Material to Be Filled in Bag?
2. Wight Capacity of Single Bag ?
3. How Many Bags Fill Per Hour?
4. Your Materials Characte?


Chemical 200bag/H 25kg Weighing Valve Bagging Machine 2


Valve Bag Packer



The parameter and function table of the valve bag packer:



DCS-25PV1(1)

(exhausting type)

DCS-25PV1(2)

(screw type)

DCS-25PV1(3)

(airflow type)

DCS-25PV1(5)

(horizontal impeller)

DCS-25PV1(6)

(vertiacl impeller)



Scope of application



Suitable materials



Powder and ultrafine powder of good Air affinity



Powder and thin granule



Powder and thin granule



Powder and ultrafine powder



Powder and ultrafine powder



Suitable packing container

Upper and lower spiral air supply single screw air flow Horizontal impeller Vertical impeller



Technical parameters



Weighing range(Kg)

10-50 10-50 10-50 10-50 10-50



Packing speed(bag/H)

30-180 30-120 30-200 30-250 30-250



Packing Accuracy



Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)



Control function



Automatic tare



Automatic quick and slow feeding



Automatic free fall compensation



Automatic minus deviation

× ×



Automatic over weight alarms



Automatic self diagnosis failure



Manual/Automatic mode conversation



Communication port



Regulatory function



Manual adjusting the height of bag



Suit for open and valve bag function



Important auxiliary function



Blow bag function in advance



Arch break function of hopper



Vibration at the bottom of the bag



Powder protection



Inflatable seal

× × ×



Negative pressure dusting(not contain duster)



Automatic blow valve mouth

×



Safety protection



Electrostatic grounding



ionic wind remove static



Stop packing when lose power



Emergency stop



Ex-proof



Mark: “○”is standard function;“▲”is choose function ;“×”is not has function





main features:

*valve bag packing for Powder and ultrafine powder.

*Can be twin-type packer

*Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.
