Brief induction:
The automatic bagging machine can quickly and efficiently fill bags with flakes, and granular products up to 300 bags per hour. Each bag filling machine can operate independently or as a part of a complete packaging system with conveyors, palletizers, palletizing robots and stretch wrappers.
Technical Parameters:
| Hopper No. | Single | Double |
| Aplicable | Sintered Tabular Alumina, Bauxite, Mullite, White Fused Alumina, Brown Fused Alumina, Silicon Carbide, Fluorspar etc | |
| Weighing range | 5-25 kg/bag | |
| Packing speed | 180-300 bags/hour | 360-480 bags/hour |
| Weighing accuracy | ±0.2% | |
| Feeding mechanism | Gravity feeder | |
| Air source pressure | 0.4-0.8 MPa | |
| Voltage | Single phase AC220V, three phase 380V, 50Hz, or customize | |
| Power | 2.5kw | 5kw |
| Dimension | 3000*1100*2450mm | 3000*1100*3100mm |
| Working environment |
-20℃-50℃ |
|
Weighing bagging machine application :
This machine is applicable to weighing of Sintered Tabular Alumina, Bauxite, Mullite, White Fused Alumina, Brown Fused Alumina, Silicon Carbide, Fluorspar etc that are granular material, and quantitative packing of finished products or semi-finished products from the industry of cereals, chemical, Light Manufacturing & Foodstuffs, etc.
Weighing bagging machine Equipment consists of :
1. Automatic filling system
2. Automatic weighing balance
3. Automatic belt conveyor
4. Automatic sewing machine
5. Electric control cabinet
Characteristics :
1. Automatic weighing, filling and packing for granular material;
2. Precise weighing and bagging;
3. All automatic control of fast and slow intake, weighing and letting down of the bag
4. All the working parameters are input on the mimic panel;
5. Auto minus of the weight and auto zero resetting:
6. The imported intellective weighing instrument can display the gross weight and net weight at the same time;
7. Automatic test and correct the weighing errors;
8. It can be connected to the computer for rational management of production
Features :
1. New controller with high precision,working stable, can display the total weight,number of package, easy operation.
2. The adaptive software,having the function of automatic control parameters setting, automatic drop revising,over - weight warning and auto-diagnosis.
3. Wide packing range, high precision, it can match well with conveyor and sewing machine.
4. Weighing bagging machine using imported sensor, pneumatic actuator, easy maintenance and non-pollution.
5. The main material body is carbon steel, with painted plastic. And material contact part is stainless iron , corrosion resistance, long service life.
6. Communication interface can be offered if need, realization of data communication with PC.
Application:
This machine is applicable to weighing of Sintered Tabular Alumina, Bauxite, Mullite, White Fused Alumina, Brown Fused Alumina, Silicon Carbide, Fluorspar etc that are granular material, and quantitative packing of finished products or semi-finished products from the industry of cereals, chemical, Light Manufacturing & Foodstuffs, etc.
Equipment consists of:
1. Automatic filling system
2. Automatic weighing balance
3. Automatic belt conveyor
4. Automatic sewing machine
5. Electric control cabinet
