25 Kg Automatic Bagging and Palletizing System Automatic weighing and boxing line

25 Kg Automatic Bagging and Palletizing System Automatic weighing and boxing line

25 Kg Automatic Bagging and Palletizing System Automatic weighing and boxing line
video
25 Kg Automatic Bagging and Palletizing System Automatic weighing and boxing line
Product Details:
Place of Origin: Suzhou
Brand Name: Sanhe
Certification: ISO9001:2015, CE
Model Number: DCS-25
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wood Pallet
Delivery Time: 90 days
Payment Terms: L/C, T/T
Supply Ability: 90 Sets Per Month
Contact Now
Detailed Product Description
Product Name: DCS-25 25 Kg Automatic Bagging And Palletizing System Used For: Particles Weighing Filling
Power Supply: Electric Accuracy: Generally (+/- )0.2%FS,2δ
Origin: Suzhou Weighing Range(kg): 25 Kg
High Light:

automatic bag filling machine

,

automatic bagging equipment

25 Kg Automatic Bagging and Palletizing System Automatic weighing and boxing line



Advantage of 25 kg semi-automatic weighing packing bagging machine :

1). Just need connect the to the customer's hopper to our our packing machine buffer hopper, Or use the elevator to lift the materials from the ground to our packing machine buffer hopper .
This not only saves labor costs for enterprises, but also improves work productivity.

2). Different products have different feeding methods:
There are gravity arc door feeding, screw feeding , air flow feeding,

3). Electronic packaging scale is mainly applicable to automatic quantitative packaging of various granular materials, such as metering packaging of various granular materials such as soybean meal, feed, seed, building materials, compound fertilizer, chemical raw materials, etc.

4). The electronic packaging scale is easy to clean and maintain, with few transmission parts , low failure rate.

5). Fast packing speed, high weight accuracy, low dusting.

6). The contact part of the electronic packaging scale is made of stainless steel, which has strong corrosion resistance, high hygiene standards and long service life of the equipment.

7). High precision weighing sensor: grade 0.2 weighing sensor is selected. Intelligent weighing display controller: high resolution, high-speed A / D conversion, weighing out of tolerance, zero out of tolerance alarm, various standard data communication interfaces, etc.

8). Composition of big bag weighing packing machine:
A. Buffer hopper ( in order to provide a Continuous and stable material flow) ;
B. Weighing part: through the weighing load cell ;
C. Feeding part ( arc door feeding / screw feeding / air flow feeding / Impeller feeding , available )
D. Unloading part;

9). Load cell and digital weighing controller. Automatically start, Automatically tare, Automatically free fall compensation.

25 Kg Automatic Bagging and Palletizing System Automatic weighing and boxing line 0

25 Kg Automatic Bagging and Palletizing System Automatic weighing and boxing line 1



operation flow chart.
1. load on bag
2. peeling weight
3. fast feeding
4. slow feeding
5. finish filling
6. seal / sew bag mouth


the following optional operation :
1. metal detection ,
2. weight checker ,
3. remove the bag with weight over error,
4. inkjet printer ,
5. automatic palletizer,
6. auto pallet wrap machine / stretch hood machine



The parameter and function table :

  DCS-25
Scope of application
Suitable materials Granular material or powder material with fine flowability
Suitable packing container Open mouth bag, box, barrel
Feeding type Gravity
Alternative feeding type Vibrator
Technical parameters
Weighing range(Kg) 25 kg
Packing speed(bag/H) 160-180 bag / H ( Gross weight ) 200-300 bags / H ( Net weight )
Packing Accuracy Generally ( +/- ) 0.2% FS, 2δ ( Note : special materials shall depend on the industrial standard )





Product usuage :

--This machine is suitable for many kinds of powder such as:

--Milk powder ,flour ,rice powder ,protein powder ,Seasoning powder, chemical powder, medicine powder,coffee powder ,soy flour Etc.

--Milk powder filling machine ,flour powder filling machine ,coffee powder filling machine





95% of China Silica factory use our packing machine.we sales to India, moroco, france, USA, Thailand, and other countries.


Our competitive products:
1. gravity type packing scale
2. screw type packing scale
3. airflow type packing scale
4. automatic carton box (bags in carton box) packing line
5. automatic valve bag packing line
6. automatic air-removing packing line







DCS-25GO7N)

net weight type for granules

DCS-25(PO2G)

Gross weight type for granules

DCS-25(PO2N)

Net weight type for powder

DCS-25(PO4G)

Vertical screw type



Scope of application



Suitable materials



Granular material or powder material with fine flowability



powder material or Fine powder



powder material



Easy to bridging or raised dust of ultrafine powder



Suitable packing container



Open mouth bag, box, barrel



Open mouth bag, box, barrel



Open mouth bag, box, barrel



Open mouth bag, box, barrel



Feeding type



Gravity



horizontal screw



horizontal screw



Vertical screw



Alternative feeding type



Vibrator



Vibrator, belt



Vibrator, belt

×



Technical parameters



Weighing range

1-100 10-50 10-50 1-50



Packing speed(bag/H)

300-800 100-200 100-500 100-180



Packing Accuracy



Generally (+/- )0.2% ( Note: special materials shall depend on the industrial standard )



Control function



Automatic tare



Automatic quick and slow feeding



Automatic free fall compensation



Automatic minus deviation

Automatic over weight alarms
diagnosis failure



Manual/Automatic mode conversation



Communication port



Regulatory function

Manual adjusting the height of bag
Important auxiliary function
Arch break function of hopper ×
Vibration at the bottom of the bag
Powder protection
Inflatable seal
Negative pressure dusting(not contain duster)
Valve for leak-proof ×



Safety protection

Electrostatic grounding
ionic wind remove static
when lose power
Emergency stop
Ex-proof
Original mode DCS-25 DCS-25FW DCS-25F DCS-25FL
Mark: “○”is standard function;“▲”is choose function ;“×”is not has function



Main specialty

  • Scope of application: Granular material or powder material of Packing bags(boxes and pails)
  • Can be made into twin-type pakcer(except DCS-25(GO7N)和DCS-25(PO4G))
  • Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.
