25kg powder packing machine automatic packing line
A. What is the 25 kg Superfine powder packing machine ?
It is used to transport materials (normally powder or granule ) from the silo to the packaging container, and it also has the function of weighing,
Automatic powder packaging machine -- Automatic superfine powder vertical spiral lifting packaging machine technical parameters:
1. Measurement method: weighing type (weighing together with packing bag)
2. Feeding mode: spiral feeding (horizontal screw and vertical screw)
3. Package weight: 25 kg
4. Packaging accuracy: ≤± 0.2%
5. Packing speed: ≤ 2-3 bags / min
6. The sewing mode of vertical spiral automatic superfine powder packing machine: hot sealing machine + sewing machine + paper edge wrapping machine
Our company's automatic powder packing machine is a kind of powder vertical screw conveyor, including horizontal screw conveyor and vertical screw conveyor
Horizontal screw conveyor and vertical screw conveyor are installed vertically, including bag feeding device, bagging mechanism, lifting and weighing device, feeder, pinch shaping machine, vertical bag conveyor, etc.
The bag clamping device of the automatic powder packaging machine is driven by the lifting device to lift the conveying pipe, which can keep a small distance from the material falling to the precipitation, and the space for blanking is small, which can improve the measurement accuracy.
Our competitive products:
1. gravity type packing scale
2. screw type packing scale
3. airflow type packing scale
4. automatic carton box (bags in carton box) packing line
5. automatic valve bag packing line
6. automatic air-removing packing line
The parameter and function table :
| |
DCS-25 Superfine powder packing machine |
| Scope of application |
| Suitable materials |
Granular material or powder material with fine flowability |
| Suitable packing container |
Open mouth bag, box, barrel |
| Feeding type |
Gravity |
| Alternative feeding type |
Vibrator |
| Technical parameters |
| Weighing range(Kg) |
25 kg |
| Packing speed(bag/H) |
160-180 bag / H ( Gross weight ) 200-300 bags / H ( Net weight ) |
| Packing Accuracy |
Generally ( +/- ) 0.2% FS, 2δ ( Note : special materials shall depend on the industrial standard ) |
Product usuage : Superfine powder packing machine
--This machine is suitable for many kinds of powder such as:
--Milk powder ,flour ,rice powder ,protein powder ,Seasoning powder, chemical powder, medicine powder,coffee powder ,soy flour Etc.
--Milk powder filling machine ,flour powder filling machine ,coffee powder filling machine
95% of China Silica factory use our packing machine.we sales to India, moroco, france, USA, Thailand, and other countries.
part of our customers:
EVONIK
WACKER
BAYER
ELIOKEM
SOLVAY
BASF
LANXESS
DANISCO
LYNAS
