Open Mouth Weighing Bagging Machine For Granular Material
DCS-25GO7N) net weight type for granules |
DCS-25(PO2G) Gross weight type for granules |
DCS-25(PO2N) Net weight type for powder |
DCS-25(PO4G) Vertical screw type |
|
Scope of application |
||||
Suitable materials |
Granular material or powder material with fine flowability |
powder material or Fine powder |
powder material |
|
Suitable packing container |
Open mouth bag, box, barrel |
Open mouth bag, box, barrel |
Open mouth bag, box, barrel |
Open mouth bag, box, barrel |
Feeding type |
Gravity |
horizontal screw |
horizontal screw |
Vertical screw |
Alternative feeding type |
Vibrator |
Vibrator, belt |
Vibrator, belt |
× |
Technical parameters |
||||
Weighing range |
1-100 | 10-50 | 10-50 | 1-50 |
Packing speed(bag/H) |
300-800 | 100-200 | 100-500 | 100-180 |
Packing Accuracy |
Generally (+/- )0.2% ( Note: special materials shall depend on the industrial standard ) |
|||
Control function |
||||
Automatic tare |
○ | ○ | ○ | ○ |
Automatic quick and slow feeding |
○ | ○ | ○ | ○ |
Automatic free fall compensation |
○ | ○ | ○ | ○ |
Automatic minus deviation |
▲ | ▲ | ▲ | ▲ |
Automatic over weight alarms | ○ | ○ | ○ | ○ |
diagnosis failure | ○ | ○ | ○ | ○ |
Manual/Automatic mode conversation |
○ | ○ | ○ | ○ |
Communication port |
▲ | ▲ | ▲ | ▲ |
|
||||
Manual adjusting the height of bag | ○ | ○ | ○ | ○ |
Important auxiliary function | ||||
Arch break function of hopper | × | ○ | ○ | ○ |
Vibration at the bottom of the bag | ▲ | ▲ | ▲ | ▲ |
Powder protection | ||||
Inflatable seal | ▲ | ▲ | ▲ | ▲ |
Negative pressure dusting(not contain duster) | ▲ | ○ | ○ | ○ |
Valve for leak-proof | × | ▲ | ▲ | ▲ |
Safety protection |
||||
Electrostatic grounding | ▲ | ▲ | ▲ | ▲ |
ionic wind remove static | ▲ | ▲ | ▲ | ▲ |
when lose power | ○ | ○ | ○ | ○ |
Emergency stop | ○ | ○ | ○ | ○ |
Ex-proof | ▲ | ▲ | ▲ | ▲ |
Original mode | DCS-25 | DCS-25FW | DCS-25F | DCS-25FL |
Mark: “○”is standard function;“▲”is choose function ;“×”is not has function |
Main specialty
