25kg Open Mouth Bag Automatic Packaging Machine For Ultrafine Powder
1 Set
MOQ
Negotiable
Price
25kg Open Mouth Bag Automatic Packaging Machine For Ultrafine Powder
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: Sanhepmt
Certification: ISO9001:2015, CE
Model Number: DCS-25FWG
High Light:

Ultrafine Powder Automatic Bagging Machine

,

25kg Automatic Packaging Machine

,

Ultrafine Powder Automatic Packaging Machine

Payment & Shipping Terms
Packaging Details: Wood pallet , The pallet size is customized according to different products
Delivery Time: 90 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 30 Sets Per Month
Specifications
Product Name: Super Fine Powder Weighing Packing Machine
Weighing Range: 25kg
Speed: Depend On The Materials To Be Packed
Warranty: 1 Year
Power KW: 3 KW
Automatic Level: Semi-automatic
Product Description

 25kg Open Mouth Bag Weighing Automatic Packaging Machine For Ultrafine Powder



Nano Meter Super fine Carbon Black Powder Weighing Packing Machine



Technical Parameter Of our Valve Bag Weighing Packing Machine :

Quantitative range (Kg): 25 Kg / bag

Packing speed (package/hour): depend on the materials to be packed

Packaging Accuracy: depend on the materials to be packed



Type

DCS-25FWG

(Gross Weight Exhaust Type)

DCS-25FG

( Net weight exhaust type))

Packing capacity (pack/hour)





60-120



100-200

Package weight range (kg)





15-50



15-50



Weighing accuracy





±0.5%@2δ(25kg/bag)



±0.5%@2δ(25kg/bag)



Advantages of our Valve Bag Weighing Packing Machine :

High accuracy
Easy clean out and maintence
After the machine installs you get hands on training and documentation
The air flow feed system is capable of high production rates while maintaining good accuracies.
Operator friendly easy set
Universal and industrial components give the machinery extra long life
Manufactured to comply above and beyond international standards
PLC controller interface
The flexible and modular Packing System



A. What is 25 kg/bag electronic weighing packing scale:

Electronic packing scale consists of weighing unit, pneumatic system, dust removal system, quantitative packing control, etc. the whole weighing process is controlled by PLC and completed automatically.



B. Working principle of 25 kg/bag electronic weighing packing scale:

When the electronic packaging scale enters the automatic operation state, the weighing control system opens the feeding door to start feeding, which is a fast and slow feeding mode; when the material weight reaches the fast feeding setting value, stop the fast feeding and keep the slow feeding; when the material weight reaches the final setting value, close the feeding door to complete the dynamic weighing process;



At this time, the system checks whether the bag clamping device In the predetermined state, when the packaging bag has been clamped, the system sends a control signal to open the unloading door of the weighing bucket, and the material enters the packaging bag.



The bag clamping device will be released, and the packaging bag will fall automatically; after the packaging bag falls, the sewing bag will be carried out and transported to the next station. It operates automatically in such a cycle.

DCS-25(GO7N)Net Weight Type for Granules 25 Kg Packing Scale Machine 0

operation flow chart.

1. load on bag
2. peeling weight
3. fast feeding
4. slow feeding
5. finish filling

The material (to be packed) parameter of Bagging Machine:
A. Product name ?
B. Diameter of the material (um or mm) ?
C. Form of product ( Granule or powder ) ?
D. Bulk density(ton/m3) ?
E. Flow ability ?
F. Moisture absorption ?
G. Causticity ?
H. Toxicity ?
I. Degree of ex-proof protection for the packing machine parts ?

Packing Paramete of Bagging Machine :
A. Packing speed (bag/hour) ? how many bags per hour ?
B. Packaging weight per bag ( KG/bag ) ?
C. What is the packing kg accuracy ?



Part of our customers :
EVONIK
WACKER
BAYER
ELIOKEM
SOLVAY
BASF
LANXESS
DANISCO
LYNAS
HUBER
RHODIA
